Junction blocks

Universal use, even under harsh conditions

Available in:

156 versions

Junction blocks from Balluff connect sensors and actuators to the controller. They are especially well-suited for harsh conditions and are ideal when coolants and lubricants are used. Their fully encapsulated housing offers a high degree of protection and an outstanding resistance to shock and vibrations.

Their design makes these interfaces suitable for any equipment or machine. Metal screw inserts guarantee accurate fit of the connectors.

All junction blocks can be installed on any standard profile or base plate: Their mounting holes are placed in the center. And additional mounting holes on the side make it possible to also mount the passive interface on the side. Flexible installation assisted by highly visible LEDs.

The most important benefits

  • Easy connections
  • Low space requirements
  • Resistant to vibrations and shock
  • Robust and industrial grade
  • Media-resistant thanks to metal screw inserts
  • Flexible mounting options
  • High fitting precision of the plug connectors thanks to metal screw inserts

Availability

Price

156 Results

Order code Price Connection slots Switching function display Output current max. Cable Signal type Switching function
Actions

BPI0099

BPI 8M4A5P-2K-B0-KPXL0-050
231.4 CAD 8x M12x1-Female, 5-pin 16x LED yellow 4 A PUR black, 5 m, Drag chain compatible PNP NO/NC

BPI00A7

BPI 4M303P-5K-B0-SM48T
163.26 CAD 4x M8x1-Female, 3-pin 4x LED yellow 2 A PNP Normally open (NO)

BPI008T

BPI 8M4A5P-2K-B0-SM6LT
251.34 CAD 8x M12x1-Female, 5-pin 16x LED yellow 4 A PNP NO/NC

BPI0093

BPI 8M4A4P-2K-B0-KPXB0-150
290.64 CAD 8x M12x1-Female, 4-pin 8x LED yellow 4 A PUR black, 15 m, Drag chain compatible PNP Normally open (NO)

BPI009A

BPI 8M4A5P-2K-B0-KPXL0-100
300.05 CAD 8x M12x1-Female, 5-pin 16x LED yellow 4 A PUR black, 10 m, Drag chain compatible PNP NO/NC

BPI00CC

BPI 4M304P-5K-B0-KPXA0-030
190.18 CAD 4x M8x1-Female, 4-pin 8x LED yellow 3 A PUR black, 3 m, Drag chain compatible PNP NO/NC

BPI008N

BPI 4M4A4P-2K-B0-SM6CT
190.1 CAD 4x M12x1-Female, 4-pin 4x LED yellow 4 A PNP Normally open (NO)

BPI008P

BPI 8M4A4P-2K-B0-SM6CT
212.39 CAD 8x M12x1-Female, 4-pin 8x LED yellow 4 A PNP Normally open (NO)

BPI008Y

BPI 4M4A5P-2K-B0-SM6LT
228.22 CAD 4x M12x1-Female, 5-pin 8x LED yellow 4 A PNP NO/NC

BPI0090

BPI 8M4A4P-2K-B0-KPXB0-030
168.01 CAD 8x M12x1-Female, 4-pin 8x LED yellow 4 A PUR black, 3 m, Drag chain compatible PNP Normally open (NO)

M12 port plug connection

  • Connection with 12-pin and 19-pin M23 plug connector

  • Variants for one or two signals per port

  • 4-way and 8-way versions of PNP, NPN and variants without LED available

M12 port cable connection

  • Various cable lengths

  • Variants for one or two signals per port

  • 4- and 8-way versions

  • Variants for PNP and NPN sensors and variants without LED

M12 port hood-type outlet

  • Connection via plug strips

  • Galvanic isolation of the power supply for the sensors and actuators via jumpers possible

  • Variants for one or two signals per port

  • 4- and 8-way versions

  • Variants for PNP sensors

M8 port cable connection

  • Various cable lengths

  • Variants for one or two signals per port

  • 4-, 6-, 8-,10-way versions

  • Variants for PNP and NPN sensors and variants without LED

  • Flexible assembly thanks to mounting hole for lateral or front assembly

M8 port plug connection

  • Connection with 8-pin or 12-pin M12 plug connector

  • Variants for one or two signals per port

  • 4-, 6-, 8-,10-way versions

  • Variants for PNP and NPN sensors and variants without LED

  • Flexible assembly thanks to mounting hole for lateral or front assembly
