Similar Illustration
Only CAD model download is supported
Cylindrical version
Housing material
Brass, Nickel-free coated
Housing material
Metal
Measuring range
7...11 mm
Connection type
Connector
Interface
2x PNP/NPN//push-pull NO/NC IO-Link 1.1
Do you have any questions about the product?
Get in touch with us.
This product page contains information for Koera – Balluff Korea Ltd., Gyeonggi-do
Alternative products
|
|
Alternative
|
|
|
|
|
|
| BES M12MC1-YIC10F-S04G | BES M12MF1-YIC10F-S04G | |
|
89,050 KRW
List price
|
89,050 KRW
List price
|
|
| Housing material | Brass, Nickel-free coated | Brass, Nickel-free coated |
|---|---|---|
| Housing material | Metal | - |
| Measuring range | 7...11 mm | - |
| Connection type | Connector | - |
| Interface | 2x PNP/NPN//push-pull NO/NC IO-Link 1.1 | - |
| IP rating | IP68 | - |
| Installation | non-flush | non-flush |
| Approval/Conformity |
CE UKCA cULus WEEE |
CE UKCA cULus WEEE |
| Principle of operation | Inductive sensor | - |
| Range | 7...11 mm | 7...11 mm |
| Connector 01, style | M12x1 | - |
| Style Housing | M12x1 | M12x1 |
| Dimension | - | Ø 12 x 60 mm |
| Interface | - | IO-Link 1.1 |
| Switching output | - | 2x PNP/NPN/push-pull NO/NC |
| Switching frequency | - | 500 Hz |
| Material sensing surface | - | PBT |
| Connection | - | Connector, M12x1-Male, 4-pin |
| Operating voltage Ub | - | 18...30 VDC |
| Ambient temperature | - | -25...70 °C |
| IP rating | - | IP68, according to BWN Pr 20 |
