Field attachables
Connection
M8x1-Male, straight, 3-pin, A-coded
Number of connectable contacts
3
Connection cross-section
0.25 mm²
Cable diameter D
5.00 mm
Operating voltage Ub
30 VDC
Recommended alternative
How does the alternative product differ from the discontinued one?
Do you have any questions about the product?
This product page contains information for Sweden – Balluff AB, Göteborg
Alternative products
|
Discontinued
|
Recommended alternative
|
|
|
|
|
|
BCC014HBKS-S 82-00- |
BCC06YZBCC M333-0000-20-000-34X325-000- |
|
| Connection | M8x1-Male, straight, 3-pin, A-coded | M8x1-Male, straight, 3-pin, A-coded |
|---|---|---|
| Number of connectable contacts | 3 | 3 |
| Connection cross-section | 0.25 mm² | 0.14...0.34 mm² |
| Cable diameter D | 5.00 mm | 3.5...5 mm |
| Operating voltage Ub | 30 VDC | 60 VDC / 60 VAC |
| IP rating | IP67 | IP67 |
| Ambient temperature | -40...85 °C | -40...85 °C |
| Approval/Conformity |
EAC WEEE |
CE cULus WEEE |
