Field attachables
Connection
M8x1-Female, straight, 4-pin, A-coded
Number of connectable contacts
4
Connection cross-section
0.14...0.5 mm²
Type of wire mounting
Screw terminals
Cable diameter D
3.5...5 mm
Recommended alternative
How does the alternative product differ from the discontinued one?
Do you have any questions about the product?
This product page contains information for Sweden – Balluff AB, Göteborg
Alternative products
|
Discontinued
|
Recommended alternative
|
|
|
|
|
|
BCC015ABKS-S149-00- |
BCC06Z5BCC M334-0000-10-000-31X450-000- |
|
| Connection | M8x1-Female, straight, 4-pin, A-coded | M8x1-Female, straight, 4-pin, A-coded |
|---|---|---|
| Number of connectable contacts | 4 | 4 |
| Connection cross-section | 0.14...0.5 mm² | 0.14...0.5 mm² |
| Type of wire mounting | Screw terminals | Screw terminals |
| Cable diameter D | 3.5...5 mm | 3.5...5 mm |
| Operating voltage Ub | 30 VDC | 60 VDC / 60 VAC |
| IP rating | IP67 | IP67 |
| Ambient temperature | -40...85 °C | -40...85 °C |
| Approval/Conformity |
EAC WEEE |
CE cULus WEEE |
