Inductive proximity switches and proximity sensors
Dimension
80 x 80 x 50 mm
Style Housing
80x80
Installation
for flush mounting
Range
40 mm
Switching output
PNP normally open/normally closed (NO/NC)
Recommended alternative
How does the alternative product differ from the discontinued one?
Do you have any questions about the product?
This product page contains information for Sweden – Balluff AB, Göteborg
Alternative products
|
Discontinued
|
Recommended alternative
|
|
|
|
|
|
BES02RMBES IKG-040.38-G-S4- |
BES0225BES Q80KA-PAH40B-S04Q- |
|
| Dimension | 80 x 80 x 50 mm | 106 x 80 x 40 mm |
|---|---|---|
| Style Housing | 80x80 | 80x80 |
| Installation | for flush mounting | for flush mounting |
| Range | 40 mm | 40 mm |
| Switching output | PNP normally open/normally closed (NO/NC) | PNP normally open/normally closed (NO/NC) |
| Switching frequency | 100 Hz | 50 Hz |
| Housing material | Aluminium | PBT, GF30 |
| Material sensing surface | Plastic | PBT, GF30 |
| Connection | Connector, M12x1-Male, 4-pin | Connector, M12x1-Male, 4-pin |
| Operating voltage Ub | 10...55 VDC | 10...55 VDC |
| Ambient temperature | -25...70 °C | -25...70 °C |
| IP rating | IP67 | IP67 |
| Approval/Conformity |
CE EAC WEEE |
CE UKCA WEEE |
