Similar Illustration
Canceled
Only CAD model download is supported
Fiber optic sensors
Version
5x10, light grid
Use
for fiber optic base units BFB
Reference base unit
BFB 75K-001-..
Fiber type material
PMMA
Cable length L
2 m
Recommended alternative
BFO00AP
Fiber optic sensors
BFO D22-LA-GD-EAK-52-02
Availability
How does the alternative product differ from the discontinued one?
Do you have any questions about the product?
Get in touch with us.
This product page contains information for Sweden – Balluff AB, Göteborg
Alternative products
|
Discontinued
|
Soon no longer available
Recommended alternative
|
|
|
|
|
|
| BFO D22-LA-AD-EAK-52-02 | BFO D22-LA-GD-EAK-52-02 | |
|
-
List price
|
-
List price
|
|
| Version | 5x10, light grid | 5x10, light grid |
|---|---|---|
| Use | for fiber optic base units BFB | for fiber optic base units BFB |
| Reference base unit | BFB 75K-001-.. | BFB 75K-001-.. |
| Fiber type material | PMMA | PMMA |
| Cable length L | 2 m | 2 m |
| Material jacket | PE | PE |
| Range | 450 mm | - |
| Ambient temperature | -35...65 °C | -55...70 °C |
| Material | Brass nickel-plated | Brass nickel-plated |
| Active surface, fibers | Ø 0.25 mm (16x) | Ø 0.25 mm (16x) |
| Active surface, fiber arrangement | Row | Row |
| IP rating | IP65 | IP65 |
Only CAD model download is supported
