Distance sensors with metal housing and different types of light
Series
66M
Dimension
30 x 100.5 x 73.2 mm
Interface
Analog, current 4…20 mA linear rising/falling PNP/NPN NO/NC
Principle of operation
Photoelectric distance sensor
Principle of optical operation
Triangulation
Do you have any questions about the product?
This product page contains information for Sweden – Balluff AB, Göteborg
Alternative products
|
Available
|
Alternative
|
|
|
|
|
|
BOD001CBOD 66M-RB11-S92- |
BOD001HBOD 66M-RA11-S92- |
|
| Series | 66M | 66M |
|---|---|---|
| Dimension | 30 x 100.5 x 73.2 mm | 30 x 100.5 x 73.2 mm |
| Interface | Analog, current 4…20 mA linear rising/falling PNP/NPN NO/NC | Analog, voltage 1…10 V linear rising/falling PNP/NPN NO/NC |
| Principle of operation | Photoelectric distance sensor | Photoelectric distance sensor |
| Principle of optical operation | Triangulation | Triangulation |
| Beam characteristic | Divergent | Divergent |
| Light type | LED, red light | LED, red light |
| Light spot size | Ø 15 mm at 600 mm | Ø 15 mm at 600 mm |
| Range | 100...600 mm | 100...600 mm |
| Accuracy | ±1.5 % FS | ±1.5 % FS |
| Repeat accuracy | 0.5 %FS | 0.5 %FS |
| Resolution | 100...500 µm | 100...500 µm |
| Connection | Connector, M12x1-Male, 5-pin | Connector, M12x1-Male, 5-pin |
| Housing material | Zinc, Die casting, Painted | Zinc, Die casting, Painted |
| Operating voltage Ub | 18...30 VDC | 18...30 VDC |
| Approval/Conformity |
CE WEEE |
CE WEEE |
