BCC0KL6

BCC Z032-0000-10-148-VS0CT4-050

Single-ended cordsets

Connection
Hirose 10A-10P-12S-Female, straight, 12-pin
Cable
PVC Shielded black, 5 m
Number of conductors
12
Conductor cross-section
24 AWG
Cable temperature, fixed routing
-30...80 °C
Do you have any questions about the product? Get in touch with us.
This product page contains information for Belgium

Quantity scale

Contact request
Key features
Connection
Hirose 10A-10P-12S-Female, straight, 12-pin
Cable
PVC Shielded black, 5 m
Number of conductors
12
Conductor cross-section
24 AWG
Cable temperature, fixed routing
-30...80 °C
Cable temperature, flexible routing
-15...80 °C
Operating voltage Ub
140 VDC / 100 VAC
Rated current (40 °C)
2.0 A
IP rating
IP50
Cable jacket, color
black
Approval/Conformity
CE
WEEE
Classifications
ECLASS 10.1
27-06-03-11
ECLASS 11.0
27-06-03-11
ECLASS 12.0
27-06-03-11
ECLASS 13.0
27-06-03-11
ECLASS 14.0
27-06-03-11
ECLASS 4.1
27-27-90-01
ECLASS 5.1.4
27-27-92-01
ECLASS 6.2
27-27-92-01
ECLASS 8.1
27-27-92-18
ECLASS 9.0
27-06-03-11
ECLASS 9.1
27-06-03-11
ETIM 4.0
EC001855
ETIM 5.0
EC001855
ETIM 6.0
EC001855
ETIM 7.0
EC001855
ETIM 8.0
EC001855
ETIM 9.0
EC001855
UNSPSC 11
26121604
UNSPSC 7.0901
26121604
