Junction blocks
Universal use, even under harsh conditions
Available in:
118 versions
Junction blocks from Balluff connect sensors and actuators to the controller. They are especially well-suited for harsh conditions and are ideal when coolants and lubricants are used. Their fully encapsulated housing offers a high degree of protection and an outstanding resistance to shock and vibrations.
Their design makes these interfaces suitable for any equipment or machine. Metal screw inserts guarantee accurate fit of the connectors.
All junction blocks can be installed on any standard profile or base plate: Their mounting holes are placed in the center. And additional mounting holes on the side make it possible to also mount the passive interface on the side. Flexible installation assisted by highly visible LEDs.
The most important benefits
- Easy connections
- Low space requirements
- Resistant to vibrations and shock
- Robust and industrial grade
- Media-resistant thanks to metal screw inserts
- Flexible mounting options
- High fitting precision of the plug connectors thanks to metal screw inserts
Availability
118 versions
|
Order code
|
Price | Connection slots | Switching function display | Output current max. | Cable | Signal type | Switching function | Actions |
|---|---|---|---|---|---|---|---|---|
|
572.11 DKK
Please login for individual prices.
|
8x M12x1-Female, 4-pin | Yellow LED (8x) | 4 A | PNP | normally open (NO) | |||
|
534.29 DKK
Please login for individual prices.
|
8x M12x1-Female, 5-pin | Yellow LED (16x) | 4 A | PNP | NO/NC | |||
|
619.48 DKK
Please login for individual prices.
|
8x M12x1-Female, 5-pin | Yellow LED (16x) | 4 A | PNP | NO/NC | |||
|
449.17 DKK
Please login for individual prices.
|
4x M12x1-Female, 5-pin | Yellow LED (8x) | 4 A | PNP | NO/NC | |||
|
416.12 DKK
Please login for individual prices.
|
4x M12x1-Female, 4-pin | Yellow LED (4x) | 4 A | PNP | normally open (NO) | |||
|
1371.3 DKK
Please login for individual prices.
|
2 A | PUR black, 15 m, drag chain compatible | ||||||
|
594.26 DKK
Please login for individual prices.
|
8x M12x1-Female, 4-pin | Yellow LED (8x) | 4 A | PNP | normally open (NO) | |||
|
710.04 DKK
Please login for individual prices.
|
8x M12x1-Female, 5-pin | Yellow LED (16x) | 4 A | PNP | NO/NC | |||
|
640.52 DKK
Please login for individual prices.
|
4x M12x1-Female, 5-pin | Yellow LED (8x) | 4 A | PNP | NO/NC | |||
|
472.67 DKK
Please login for individual prices.
|
8x M12x1-Female, 4-pin | Yellow LED (8x) | 4 A | PUR black, 3 m, drag chain compatible | PNP | normally open (NO) |
