BCC04KF

Name: BCC04KF
Brand: Balluff
SKU: BCC04KF
Availability: OutOfStock

BCC E834-E834-90-334-PS54T2-020

Double-ended cordsets

Connection 1

RJ45-Male, straight, 4-pin

Connection 2

RJ45-Male, straight, 4-pin

Interface

Profinet

Cable

PUR Shielded Green, 2.00 m, Drag chain compatible

Cable, note

Profinet Type C, CAT 5E by IEC 61156-6

Recommended alternative

Availability

How does the alternative product differ from the discontinued one?

Do you have any questions about the product?

	Discontinued	Recommended alternative	Further alternative	Further alternative

	BCC04KF BCC E834-E834-90-334-PS54T2-020 -	BCC0JWZ BCC E834-E834-90-334-PS54N2-020 116.24 USD	BCC0NP7 BCC E834-E834-90-334-PS54N2-015 -	BCC0K7R BCC E834-E834-90-334-PS54N2-030 123.21 USD
Connection 1	RJ45-Male, straight, 4-pin	RJ45-Male, straight, 4-pin	RJ45-Male, straight, 4-pin	RJ45-Male, straight, 4-pin
Connection 2	RJ45-Male, straight, 4-pin	RJ45-Male, straight, 4-pin	RJ45-Male, straight, 4-pin	RJ45-Male, straight, 4-pin
Interface	Profinet	Profinet	Profinet	Profinet
Cable	PUR Shielded Green, 2.00 m, Drag chain compatible	PUR Shielded green, 2 m, Drag chain compatible	PUR Shielded green, 1.5 m, Drag chain compatible	PUR Shielded green, 3 m, Drag chain compatible
Cable, note	Profinet Type C, CAT 5E by IEC 61156-6	Profinet Type C, CAT 5E by IEC 61156-6	Profinet Type C, CAT 5E by IEC 61156-6	Profinet Type C, CAT 5E by IEC 61156-6
Number of conductors	4	4	4	4
Cable temperature, fixed routing	-40...80 °C	-40...80 °C	-40...80 °C	-40...80 °C
Cable temperature, flexible routing	-20...60 °C	-20...60 °C	-20...60 °C	-20...60 °C
Operating voltage Ub	125 VDC / 125 VAC	60 VDC	60 VDC	60 VDC
Rated current (40 °C)	1.0 A	1.5 A	1.5 A	1.5 A
IP rating	IP20/IP20	IP20/IP20	IP20/IP20	IP20/IP20
Approval/Conformity	CE EAC WEEE	CE UKCA cULus WEEE	CE UKCA cULus WEEE	CE UKCA cULus WEEE
