Chemical resistant cables (stainless)
Alternative products
|
Alternative
|
Further alternative
|
|
![]() |
![]() |
![]() |
|
BCC0AHJBCC S425-0000-1A-003-VX44T2-02022.44 USD |
BCC0APHBCC S425-0000-1A-008-VX44T2-02033.88 USD |
BCC0AH2BCC S415-0000-1A-003-VX44T2-02025.98 USD |
|
Special characteristics | Washdown | Washdown | Washdown |
---|---|---|---|
Connection | M12x1-Female, angled, 5-pin, A-coded | M12x1-Female, angled, 5-pin, A-coded | M12x1-Female, straight, 5-pin, A-coded |
Switching output | antivalent | PNP NO/NC antivalent | antivalent |
Cable | PVC yellow, 2 m, Drag chain compatible | PVC yellow, 2 m, Drag chain compatible | PVC yellow, 2 m, Drag chain compatible |
Number of conductors | 4 | 4 | 4 |
Conductor cross-section | 22 AWG | 22 AWG | 22 AWG |
Cable temperature, fixed routing | -40...105 °C | -40...105 °C | -40...105 °C |
Cable temperature, flexible routing | -5...105 °C | -5...105 °C | -5...105 °C |
Operating voltage Ub | 250 VDC / 250 VAC | 30 VDC | 250 VDC / 250 VAC |
Rated current (40 °C) | 4.0 A | 4.0 A | 4.0 A |
IP rating | IP67, IP68, IP69K | IP67, IP68, IP69K | IP67, IP68, IP69K |
Approval/Conformity |
CE cULus Ecolab WEEE |
CE cULus Ecolab WEEE |
CE cULus Ecolab WEEE |
