BCC0M20

Name: BCC0M20
Brand: Balluff
SKU: BCC0M20
Availability: OutOfStock

BCC M425-0000-1A-017-PW3534-100

Single-ended cordsets

Connection

M12x1-Female, angled, 5-pin, A-coded

Switching output

antivalent

Cable

PUR welding spark resistant Orange, 10 m, drag chain compatible

Number of conductors

Conductor cross-section

0.34 mm²

Do you have any questions about the product?

	Discontinued	Alternative	Further alternative

	BCC0M20 BCC M425-0000-1A-017-PW3534-100 -	BCC087P BCC M425-0000-1A-040-PW3534-100 82.73 USD	BCC0C7R BCC M425-0000-1A-100-PW3534-100 85.19 USD
Connection	M12x1-Female, angled, 5-pin, A-coded	M12x1-Female, angled, 5-pin, A-coded	M12x1-Female, angled, 5-pin, A-coded
Switching output	antivalent	PNP NO/NC antivalent	PNP NO/NC antivalent
Cable	PUR welding spark resistant Orange, 10 m, drag chain compatible	PUR welding spark resistant orange, 10 m, Drag chain compatible	PUR welding spark resistant orange, 10 m, Drag chain compatible
Number of conductors	5	5	5
Conductor cross-section	0.34 mm²	0.34 mm²	0.34 mm²
Cable temperature, fixed routing	-50...90 °C	-50...90 °C	-50...90 °C
Cable temperature, flexible routing	-25...90 °C	-25...90 °C	-25...90 °C
Operating voltage Ub	60 VDC / 60 VAC	30 VDC	30 VDC
Rated current (40 °C)	4.0 A	4.0 A	4.0 A
IP rating	IP67, IP68, IP69K	IP67, IP68, IP69K	IP67, IP68, IP69K
Approval/Conformity	CE cULus EAC WEEE	CE cULus WEEE	CE cULus WEEE
